# Bridge Vocabulary

| See more in Industrial Automation

## Engineering Bridge Game

By
Created Date 09.16.20
Last Updated 09.19.20
Viewed 17 Times
Your browser doesn't support HTML5. System.Collections.Generic.List`1[System.String] System.Collections.Generic.List`1[System.String]
0

## Create multiple-choice games on Wisc-Online and play them on our Chakalaka mobile app!

### But that's not all! Explore educational games created by others. Simply search by category or enter agame code number and dive into a world of learning and fun.

Topics of this game:
• A strong rope, usually made of metal, designed to have great tensile strength and to be used in structures.
• The geometric center of an area.
• A body subjected to a push.
• A force system where all of the forces are applied at a common point on the body or having their lines of action with a common intersection point.
• A surface or shape exposed by making a straight cut through something at right angles to the axis.
• The direction of a vector is defined by the angle between a reference axis and the arrow’s line of direction.
• A support that prevents translation and rotation in a beam.
• A broad ridge or pair of ridges projecting at a right angle from the edge of a structural shape in order to strengthen or stiffen it.
• A diagram used to isolate a body from its environment, showing all external forces acting upon it.
• A plate or bracket for strengthening an angle in framework.
• The connection points of members of a truss.
• The absolute value of a number.
• Slender straight pieces of a truss connected by joints.
• A method of analysis of trusses which constructs free body diagrams of each joint and determines the forces acting in that joint by considering equilibrium of the joint pin.
• The turning effect of a force about a point equal to the magnitude of the force times the perpendicular distance from the point to the line of action from the force.
• A mathematical property of a cross section that is concerned with a surface area and how that area is distributed about a centroidal axis.
• Every body or particle continues at a state of rest or uniform motion in a straight line, unless it is compelled to change that state by forces acting upon it.
• The change of motion of the body is proportional to the net force imposed on the body and is in the direction of the net force.
• If one body exerts a force on a second body, then the second body exerts a force on the first body which is equal in magnitude, opposite in direction, and collinear.
• A support that prevents translation in any direction.
• A truss that lies in a single plane often used to support roofs and bridges.
• The resultant of a system of force is the vector sum of all forces.
• A support that only prevents a beam from translating in one direction.
• A physical quantity that has magnitude only.
• The sense of a vector is the direction of the vector relative to its path and indicated by the location of the arrow.
• A truss composed of triangles, which will retain its shape even when removed from supports.
• A condition where there are no net external forces acting upon a particle or rigid body and the body remains at rest or continues at a constant velocity.
• A structure or body which is over-constrained such that there are more unknown supports than there are equations of static equilibrium.
• Something made up of interdependent parts in a definite pattern of organization, such as trusses, frames, or machines.
• A body subjected to a pull.
• A quantity that has both a magnitude and direction.
|
|
